BP 125 Watt 12 Volt Silicon Nitride Multi Crystalline Solar Module (with Junction box)



High efficiency 125 watt photovoltaic module using silicon nitride MultiCrystalline cells. The BP 3125J photovoltaic module provides superior value and performance for commercial and industrial use, operating DC loads directly or, in an inverter-equipped system, AC loads.



Warranty



  • Minimum power output of 93% for the first 12 years and 85% through 25 years
  • 5-year limited warranty on materials and workmanship



Technical Specifications



Electrical Characteristics
Maximum power - Pmax 125 W
Voltage at Pmax - Vmp 17.6 V
Current at Pmax - Imp 7.1 A
Warranted minimum Pmax 118.75 W
Short-circuit current - Isc 7.54 A
Open-circuit voltage - Voc 22.1 V
Temperature coefficient of Isc (0.065 ± 0.015)% / °C
Temperature coefficient of Voc -(80 ± 10)mV / °C
Temperature coefficient of power -(0.5 ± 0.05)% / °C
Nominal operating cell temperature 38 ± 2°C
Maximum series fuse rating 15 A (20A for U version)
Maximum system voltage
  • 600V (U.S. NEC & IEC 61215 rating)
  • 1000V (TÜV Rheinland rating)
Mechanical Characteristics
Dimensions 1510 Length x 674 Width x 50Depth mm
Weight 12 kg
Solar Cells 36 cells in a 4 x 9 matrix connected in series
Frame Clear anodized aluminum alloy type 6063T6 Universal frame; Color: silver
Diodes IntegraBus™ technology includes Schottky by-pass diodes integrated into the printed circuit board bus
Junction box U-Version junction box with 6-terminal connection block; IP 54, accepts PG 13.5,
M20, ½ inch conduit, or cable fittings accepting 6-12mm diameter cable. Terminals accept 2.5 to 10mm2 wire
Construction Front: High-transmission 3mm (1/8th inch) tempered glass; Back: Tedlar; Encapsulant: EVA

Quality and Safety



  • Module power measurements calibrated to World Radiometric Reference through ESTI (European Solar Test Installation at Ispra, Italy)
  • Manufactured in ISO 9001-certified factories; conforms to European Community Directives 89/33/EEC, 73/23/EEC, 93/68/EEC; certified to IEC 61215
  • Framed modules certified by TÜV Rheinland as Safety Class II (IEC 60364) equipment for use in systems up to 1000 VDC
  • Listed by Underwriter’s Laboratories for electrical and fire safety (Class C fire rating)
  • Approved by Factory Mutual Research in NEC Class 1, Division 2, Groups C & D hazardous locations

Manuals and Downloads




Details

  • Model: BP-3125J
  • Shipping Weight: 12kg
  • Manufacturer:
    BP Solar
