In the context of renewable energy, a solar inverter is a device that will convert DC battery/solar panel voltage into mains type AC power; suitable for use in your home or business.
Check out our huge range of true sine wave inverters
Buy online - same day shipping for stocked items!
Without this conversion from DC to AC, special appliances or adapters often need to be purchased - and DC appliances are often more expensive than their AC counterparts.
The ratings that you should look at when buying an inverter (depending on the type) are:
There are basically two types of inverters: modified sine wave (aka modified square wave) and true sine wave. The differences between these two types of inverters are subtle but significant in the way they operate.
Examples of modified "sine" wave vs true sine wave:
A modified sine wave inverter can adequately power some household appliances and power tools. It is cheaper, but may present certain compromises with some loads such as computers, microwave ovens, laser printers, clocks and cordless tool chargers. Virtually all low cost inverters are "modified sine wave". A modified sine wave is easier and cheaper to produce than a sine wave inverter.
It is also a fact that cheaper modified sine wave inverters have given this type of inverter a bad name. These low cost inverters are generally available from electrical stores, hardware stores, automotive store and electronic suppliers. They usually lack many features such as auto-start or any type of tweaking ability. The devices are usually about 70% efficient, so expect some significant power losses if you are using a modified sine wave inverter in your system. We do not sell such devices.
A true sine wave inverter, also known as a digital inverter, is designed to replicate and even improve the quality of electricity supplied by utility companies. To operate higher-end electronic equipment, a sine wave inverter is recommended. Efficiency has reached up to about 98% and the electricity from these devices is of a higher quality than grid power almost anywhere in the world. We only sell this kind of solar inverter for grid connect and off-grid applications.
A high quality solar inverter for off grid applications will include:
Even among sine wave inverters, there's a great deal of difference in quality. Cheap imports are flooding our shores and in many cases, these devices will be inefficient and may pose safety issues. A long warranty is no guarantee of quality as companies can shut up shop overnight, rendering the warranty useless. Be sure to purchase a solar inverter that has been independently tested and has a demonstrated history of reliable operation for Australia's often harsh conditions.
If you have an modified sine wave inverter and suspect you need a true sine wave inverter, please note there is no ‘filter’ or ‘retrofit’ you can apply to the output of an modified sine wave inverter to clean up the output or turn it into true sine wave.
All grid connect inverters, such as those used in systems connected to mains electricity, are true sine wave units. While all grid connect inverters sold in Australia must meet minimum standards and be approved for use in conjunction with mains electricity; not all solar inverters are created equal as this video clearly shows.
A grid connect solar inverter endures high and varying voltage levels, extreme temperature ranges, moisture and dust. A quality inverter is the key to the safety, efficiency, reliability, and usability of solar power systems..
In general, any device that senses either voltage peaks or zero crossings could have problems when running from modified sine wave. Devices such as these should be run from true sine wave inverters.
Ham radio and CB radio operators may notice RF noise from modified sine wave inverters; in that case do not run the radio and the inverter at the same time. Electronics that modulate RF (radio frequency) signals on the AC line will not work and may be damaged. You may notice hum or buzz in the audio of TV’s, radios and satellite systems used with modified sine wave inverters. Audiophiles or professionals using sophisticated audio, remote measurement, surveillance or telemetry equipment should use true sine wave.
Examples of problem devices are motor speed controllers employing triacs, and some small battery rechargers that do not incorporate a transformer between the utility power and the load. To help you visualize this, if there isn’t a ‘wall wart’ between the battery charger (or the battery in the device) and the AC plug, don’t use modified sine wave.
Please note two other common problem loads, electric shavers and emergency flashlights. Both of these items have batteries in them but connect directly into the wall to charge, without an external transformer. Don’t use items like these with an modified sine wave inverter. If you do use an modified sine wave inverter with a transformer-less charger, your product will likely be damaged.
Garage door openers, laser printers and large strobes used in photography have all been reported as trouble loads for modified sine wave inverters; they either don’t work at all or stop working entirely, so don’t take a chance – use true sine wave.
As a general rule, products operating through an AC adapter will work fine from an modified sine wave inverter. These include laptops and cell phone chargers, video games, camcorder and digital camera chargers. Televisions generally work well; some VCR’s with inexpensive power supplies run poorly. Consider switching to another brand of VCR in that case.
A potential solution for RV’ers or off-grid cottagers is to purchase our smallest true sine wave inverter to run TV, VCR and audio equipment, and a larger modified sine wave inverter (such as the XPower 1750 Plus) for the coffee maker, hair dryer and microwave.
